1GE EPON Mini ONT Single-mode Fiber Modem | Otical Network Terminal Single Port
- Conform to IEEE802.3ah standard
- Support Ethernet service layer 2 switching and wire-speed forwarding of uplink and downlink services
- Support frame filtering and suppression
- Support standard 802.1Q Vlan function, support VLAN conversion
- Support 4094 VLANs (802.1Q)
- Support Dynamic Bandwidth Allocation (DBA) function
- Support QoS, including traffic flow classification, priority marking, queue and dispatch, traffic shaping and traffic control, etc
- Single ONU supports up to 1 LLID.Support IGMP Snooping.Support router
- Support Ethernet port ratelimit loop detection.Support power failure alarm
- Support lightning protection for power supply and lightning protection for service port
Product Overview
The 1GE EPON Mini ONT Single-mode Fiber Modem G51 Micro ONU is a telecom-grade EPON modem compliant with IEEE 802.3-2005. Designed for high-speed data services, it features a single-mode fiber interface, 1GE port, and advanced QoS/VLAN capabilities.
This is an entry-level fiber optic network terminal, it adopts ZTE chip solution, GPon or EPon single mode operation, it has a Gigabit Ethernet interface, supports routing function, perfectly suitable for FTTH Fiber-to-the-Home network solution, it is cheap and cost-effective, if you are interested in this product, please contact us.
Key Features of 1GE EPON Mini ONT
- 1x 10/100/1000M RJ45 Ethernet port
- Single-mode fiber PON interface (1.25Gbps symmetric)
- Supports 802.1Q VLAN (4094 VLANs)
- Dynamic Bandwidth Allocation (DBA)
- Layer 2 switching with wire-speed forwarding
- Advanced QoS: 802.1p, CoS, traffic shaping
- Rugged design with lightning protection
Technical Specifications of 1GE EPON Mini ONT Single-mode Fiber Modem
| Parameter | Specification |
|---|---|
| Model | E8010U-FZ |
| Fiber Type | Single-mode |
| PON Performance | 1.25Gbps uplink/downlink, 20km coverage |
| Optical Sensitivity | -25dBm (Receive), >0dBm (Transmit) |
| Security | ONU authentication, 802.1x, RADIUS |
| Power Supply | 100-240V AC, 12V/0.5A DC |
| Dimensions | 117×88×32mm |
| Operating Temperature | 0°C to 50°C |
Advanced Capabilities
Networking Features OF1GE EPON Mini ONT
- IGMP Snooping & Router Support
- Port-based rate limiting & loop detection
- Storm control & port protection
Management
- Web-based management interface
- TELNET remote configuration
- Power failure alarm support
Compliance & Certification
- IEEE 802.3ah EPON Standard
- China Telecom EPON V2.1 Specification
- CE/FCC/RoHS Compliant
