300M Wifi ONU Modem Router Dual-Mode GPON/EPON with Built-in WiFi & Advanced Firewall
- 1 E/GPON port(EPON PX20+ and GPON Class B+)
- Wavelength:Tx1310nm,Rx 1490nm
- SC/UPC connector
- Receiving saturation:≥8dBm
- Receivingsensitivity:≤28dBm
- Transmitting optical power: 0~+4dBm
- Transmission distance: 20KM
Product Overview
The 300M Wifi ONU Modem Router (Model: GL-X8004U-YD) is a high-performance, dual-mode (GPON/EPON) device designed for telecom operators, FTTH/FTTO deployments, SOHO networks, and video surveillance. It combines gigabit Ethernet, VoIP (POTS), USB 2.0, and 300Mbps WiFi connectivity in a compact, rugged design.
Key Features of 300M Wifi ONU Modem Router
- Dual-Mode Flexibility: Compatible with both GPON (Class B+) and EPON (PX20+) networks.
- 300Mbps Wireless Speed: Supports 802.11n WiFi with 2T2R MIMO technology for seamless coverage.
- Multi-Service Ports: 1x Gigabit Ethernet, 3x Fast Ethernet, 1x POTS (VoIP), and 1x USB 2.0.
- Advanced Security: Built-in NAT, IPv4/IPv6 dual-stack firewall, and QinQ VLAN support.
- Plug-and-Play: Auto-detection, auto-configuration, and remote firmware upgrades.
Technical Specifications of 300M Wifi ONU Modem Router
| Interface | Details |
|---|---|
| PON Port | 1x SC/UPC, 1310nm Tx / 1490nm Rx, 20km range |
| LAN Ports | 1x 10/100/1000Mbps + 3x 10/100Mbps (Auto-adaptive) |
| WiFi | 802.11b/g/n, 2.4GHz, 300Mbps max, 13 channels, MIMO support |
| POTS | 1x RJ11, G.711/G.723/G.726/G.729 codec, GR-909 compliant |
| Power | 12V DC, ≤10W consumption |
| Dimensions | 15cm x 10.3cm x 3.6cm (LxWxH), 0.21kg weight |
Advanced Functionality
- Supports IGMP Snooping for efficient multicast streaming.
- Integrated OAM for remote configuration and maintenance.
- Wide temperature operation: 0°C to +50°C (operating), -30°C to +75°C (storage).
- Compatible with Broadcom/PMC/Cortina-based OLTs.
Applications
Ideal for Fiber-to-the-Home (FTTH), Fiber-to-the-Office (FTTO), small office networks, and IP surveillance systems. Delivers reliable high-speed internet, VoIP services, and secure connectivity.
