1GE Micro HGU ONU Modem – GPON/EPON Dual Mode Adaptive

Overview

This CATV Fiber Modem FTTH 1GE Micro HGU ONU Modem is a mini compact fiber optic network broadband terminal, GPon EPon Dual Mode Adaptive mini ONU, a small home gateway device that supports routing function. It comes with one Gigabit Ethernet LAN port and one CATV port, which can convert CATV optical signals to RF electrical signals.

X11C is a residential gateway device with routing functions for xPON ONU and LAN Switch for residential and SOHO users, which is in line with ITU-T G.984 and IEEE802.3ah.

The uplink of X11C provides one PON interface, while downlink provides one Ethernet and RF interface. It can realize optical access solutions such as FTTH (Fiber To The Home) and FTTB (Fiber To The Building). It fully integrates the reliability, maintainability and security design of carrier-grade equipment, and provides customers with the last kilometer of broadband access to residential and corporate customers.

Key Features of CATV Fiber Modem FTTH

• 1GE Micro ONU with ultra-compact design (113×113×28mm)
• Dual-mode adaptive: Supports GPON/EPON networks
• Integrated CATV support for triple-play services
• SC/UPC connector for stable FTTH connectivity
• Low power consumption: 12V/0.5A DC power supply

Applications

Ideal for FTTH (Fiber-to-the-Home) deployments, IPTV/CATV signal transmission, and residential broadband solutions. Compatible with major OLT equipment.

Package Contents

• 1× 1GE Micro HGU ONU Modem
• 1× 12V/0.5A Power Adapter
• Quick Installation Guide
• Mounting Kit

Why Choose Our 1GE Micro ONU Modem?

• ✅ Space-saving design for easy installation
• ✅ Plug-and-play configuration
• ✅ Carrier-grade reliability with 50,000h MTBF
• ✅ FCC/CE/RoHS certified
