G1430C FTTH WiFi6 CATV ONU Router | Dual-Band GPON/EPON Modem
- 1*G/EPON interface: SC/UPC/APC interface,ITU-T G.984,IEEE802.3ah
- 4* Ethernet interface:10 MBPS/100 MBPS, 1000 MBPS, RJ- 45, IEEE802.3-2005 standard
- 1* VOlP interface: in accordance with G.711 a/u, G. 729 a/b, G. 722 standard
- 1 * USB interface: standard USB 3.0 interface
- Dual-band WIF16 AX3000 (2 x2 MIMO (2.4G&5G))
- 1*CATV,C/N:>43dB,C/CTB:>55dB,C/CSO>55dB,MER≥32dB,BER≤1*10E-6
Product Overview
The G1430C is a dual-band WiFi6 FTTH CATV ONU router designed for high-speed internet and multimedia services. Featuring GPON/EPON dual-mode adaptability, this ONU router ensures compatibility with major OLTs like Huawei and ZTE. With AX3000 WiFi6 technology, it delivers ultra-fast wireless speeds up to 3000Mbps, ideal for 4K streaming, gaming, and smart home applications.
Key Features OF FTTH WiFi6 CATV ONU Router
- Supports FTTH, GPON/EPON, and CATV integration
- WiFi6 AX3000 with 2.4GHz (574Mbps) + 5GHz (2402Mbps) dual-band
- 4× Gigabit Ethernet ports + 1× USB 3.0 + VoIP + CATV RF output
- Advanced QoS, IPv6 support, and TR069 remote management
Hardware Specifications OF FTTH WiFi6 CATV ONU Router
| Category | Details |
|---|---|
| Ports | 4× RJ45 (GE), 1× RJ11 (POTS), 1× SC/UPC, 1× USB 3.0, 1× CATV |
| WiFi6 | 2×2 MIMO, 64 clients, WPA3 security, WPS support |
| Dimensions | 195mm × 135mm × 40mm (L×W×H) |
| Power | 12V/1.5A DC, ≤8W consumption |
CATV System Parameters
| Parameter | Specification |
|---|---|
| C/N Ratio | >43dB |
| C/CTB | ≥55dB |
| C/CSO | >55dB |
| MER | ≥32dB |
| BER | ≤1×10-6 |
Advanced Connectivity
GPON/EPON Performance
| GPON Downstream | 2.48Gbps |
| GPON Upstream | 1.25Gbps |
| EPON Symmetric | 1.25Gbps |
| Transmission Distance | Up to 20km |
Layer 3 Features
- PPPoE/DHCP/Static IP
- IPv4/IPv6 dual stack
- NAT/NAPT, Port Forwarding
- DDNS and UPnP support
Environmental Requirements
| Operating Temperature | 0℃ to 45℃ |
| Storage Temperature | -20℃ to 70℃ |
| Humidity | 5%–95% (non-condensing) |
Compliance & Management
- Standards: IEEE 802.3ah, ITU-T G.984/G.988
- Management: Web UI, TR069, OMCI, Telnet/SSH
- Certifications: CE, RoHS, FCC (Implicit)
