XPon 1GE Mini ONU Modem X31 | Dual PON Mode | 1GE Port
- Support port – based rate limitation and bandwidth control
- In compliant with lEEE802.3ah &ITU-TG984 adaptiveinterface
- Up to 20KM transmission distance
- Support data encryption, group broadcasting, port Vlan separation ,etc.
- Support Dynamic Bandwidth Allocation (DBA)
- Support ONU auto- discovery/Link detection/remote upgrade of software
- Support port mode of VLAN configuration
- Support power – off alarm function ,easy for link problem detection
- Support broadcasting storm resistance function
- Support port loop detection
- Support ACL to configure data packet filter flexibly
- Support PPPoE/DHCP Server/IPTV/NAT
- Specialized design for system breakdown prevention to maintain stable system
- Support software online upgrading
- Support mac/port/url filter
Overview
The XPon 1GE Mini ONU Modem X31 is a compact, high-performance Optical Network Unit (ONU) designed for FTTH deployments. Featuring adaptive EPON/GPON compatibility, a 1GE Ethernet port, and advanced management capabilities, this device ensures reliable connectivity and efficient network management.
X31 Micro Mini ONU ONT HGU is a passive optical fiber network terminal independently developed by Hosecom. The device has built-in layer 2 switching function and layer 3 home gateway routing function. Small and compact, it is a high-performance, low-power consumption FTTH optical network unit. X31 mini ONU can automatically switch between EPON/GPON working modes and can be used in EPON/GPON networks, which is very suitable for the needs of operators and Internet Service Providers (ISPs) FTTH networking services.
Key Specifications of XPon 1GE Mini ONU Modem
| Model | X31 |
|---|---|
| Interface | 1×10/100/1000M RJ45 (Auto-MDIX) |
| PON Modes | EPON & GPON Adaptive |
| Transmission | Up to 20KM |
| GPON Speeds | Upstream 1.25Gbps / Downstream 2.5Gbps |
| EPON Speeds | Upstream/Downstream 1.25Gbps |
| Power | 12V/0.5A DC, <3W Consumption |
| Dimensions | 80mm×80mm×23mm (L×W×H) |
Key Features
- Dual PON Mode Support: Auto-adapts to EPON/GPON networks
- Advanced Security: Data encryption, VLAN separation, ACL filtering
- Smart Management: Web/TELNET/TR069/OAM/OMCI compatibility
- Dynamic Bandwidth Allocation (DBA) for traffic optimization
- Auto-discovery, loop detection, and remote firmware upgrades
- Extended operating temperature: 0°C to 60°C
- Broadcast storm resistance and power-off alarm function
Technical Indicators of XPon 1GE Mini ONU Modem
| LED | State | Description |
|---|---|---|
| POW | On/Off | Power status indicator |
| PON | On/Blink/Off | OLT registration status |
| LOS | On/Off | Optical signal quality |
| LAN | On/Blink/Off | Ethernet connection status |
Compliance & Applications
Compliant with IEEE 802.3ah and ITU-T G.984 standards. Ideal for:
- Residential broadband access
- IPTV and VoIP services
- Enterprise network edge devices
- Smart city infrastructure
